UHF Range Overview


40 Channel UHF CB and 60 Channel Scanner in One




This radio brings together both an integrated 40-channel UHF CB radio and a 60-channel scanner in the one unit.

An ultra-compact design and a remote or in-dash mounting control head compliments this breakthrough in technology. The UH015sx has pre programmed police scan function allowing you to listern to activity on the police bandwidth and with its Dual Listening Circuitry allows you to listen to your UHF and Scanner Channels without having to switch between Scanner and UHF Mode.

The UH015sx offers the finest components, engineering and styling. Just what you would expect from Uniden. The UH015sx is able to scan over 8500 plus receivable channels making it ideal for truck drivers, 4WD Drivers and for those persons that need it for the dual function of a UHF Transceiver and Scanner in one. The UH015sx also has a Built-in SELCALL Function allowing the user to send a series of tones that equate to a 5/6 digit number (like a telephone number) to selectively call a similarly equipped radio.

It is also VOX Hands Free Capable allowing you to operate the UH015sx with hands free operation with an optional headset microphone available. The UH015sx is the perfect solution and tool for UHF Mobile communication worldwide.

Suggested Retail: $399.00

Key Features
Designed and Engineered in Japan
Detachable Remote or In-Dash Control Head
Super Compact Size: 36mm (H) x 127mm (W) x 157.5mm (D)
5 Watts Maximum TX Output Power
40 UHF Channels^
Interference Eliminator (38 CTCSS Codes)
Digital Coded Squelch (DCS)
60 User Programmable RX Channels
Dual Listening Circuitry: Allows you to listen to your UHF and Scanner Channels without having to switch between Scanner and UHF mode
Police Scan
Band Search Function# (400-512Mhz)
3 Level Preset Squelch
Backlit Keypad and LCD Display
Wide Full Frequency LCD Display
VOX Hands Free Capable
Range Extender (Duplex) Capability
Programmable Scan Function:
Busy Channel Lockout Function
Open Scan
RF Level Bar Indicator
Built-in SELCALL Function
Group Call
Additional Features:
*Range: 18kms Typical Range in kms (line of sight)
*Range may vary depending on environmental and/or topographical conditions
^ Please note CH 22 & 23 are used for telemetry and telecommand applications, voice communications are not permitted on these channels and transmission is inhibited
># Please note not all pre-programmed service searches may operate in New Zealand
# Please note It is illegal to operate this radio transceiver outside of Australia and New Zealand
